MINI AVANT |

MINI AVANT

TECHNICAL DATA	SINGLE-PHASE	THREE-PHASE	VARIO	MINI AVANT G
Electric motor	2,2 kW – 230 V	2,2 kW – 400 V	2,2 kW – 230 V	—
Gasoline engine	—	—	—	Honda 3,3 kW – 4,0 HP
Theorical output [*]	24 ÷ 30 l/min	24 ÷ 30 l/min	2 ÷ 30 l/min	24 ÷ 30 l/min
Max. aggregate size	6 mm	6 mm	6 mm	6 mm
Max. working pressure	15 bar	15 bar	15 bar	15 bar
Compressor	220 l/m	220 l/m	220 l/m	220 l/m
Hopper capacity	140 l	140 l	140 l	140 l
Delivery distance [*]	40 ÷ 50 m	40 ÷ 50 m	40 ÷ 50 m	50 ÷ 60 m
Delivery height [*]	12 ÷ 15 m	12 ÷ 15 m	12 ÷ 15 m	15 ÷ 18 m
Filling height	64 cm	64 cm	58 cm [¥]	64 cm
Delivery manifold	Ø 35 mm	Ø 35 mm	Ø 35 mm	Ø 35 mm
Size (L x W x H)	159 x 86 x 75 cm	159 x 86 x 75 cm	159 x 86 x 75 cm	185 x 86 x 87 cm
Weight	240 kg	240 kg	240 kg	285 kg
